VIOB-CAN-03
1 x SAE J1708 or J1939/1 x CAN 2.0B or SAE J1939 supported (by module)
Proprietary form factor to release a mini-PCIe slot for additional application
Support bit rate up to 100 kbps~1 Mbps
Wide-range operating temperature
ESD and electrical protection
- Introduction
- Specification
- Order
- Download
VIOX-CAN01/VTK-CAN-03 module is a one-port high-speed CAN interface for UART with proprietary form factor design to release a mini-PCIe slot for additional application. It is easy and quick installation on device to communicate with the vehicle ECU. It complies with standard CAN 2.0B with bit rate up to 1Mbit/s and followed the corresponded protocol. To satisfy server vehicles e nvironments, VIOX-CAN01/VTK-CAN-03 module can be operated on a wide-range operating temperature from -40°C to 85°C. Besides, it is built-in ESD level ±8KV/15KV (contact/air) according to IEC 61000-4-2 to protect the system.
| Form Factor | Proprietary |
| I/O Connector | Dual 2 x 5-pin internal header |
| Function | VIOX-CAN01 - 1 x SAE J1708 or SAE J1939 protocol supported VTK-CAN-03 - 1 x CAN 2.0B or SAE J939 protocol supported (selection by switch) |
| Dimensions | 50mm (L) x 28mm (W) (1.96” x 1.1”) Weight: 8g |
| Environment | Operating temperatures: -40°C~85°C Storage temperatures: -40°C~90°C Related humidity (with system chassis): 5%~90% |
| Electrical Protection | IEC 61000-4-2 electrostatic discharge (ESD): ±8KV/15KV (contact/air) |
| Software | Driver and SDK |
VIOX-CAN01 (P/N: 10VKOBDII00X0)
Be used for VTC 1010/VTC 6210/VTC 72XX/VMC series/MVS series (by request). 1 x SAE J1708 or SAE J1939 module, proprietary form factor, UART interface
VTK-CAN-03 (P/N: 10VK00CAN01X0)
Be used for VTC 1010/VTC 6210/VTC 72XX/VMC series/MVS series (by request). 1 x CAN 2.0B or SAE J1939 module, proprietary form factor, UART interface
