IPC-720B
Intel ® 8th/9th Generation(Coffee Lake Lake-S, Coffee CoffeeLake -S Refresh) Core™ /Pentium/Celeron 14nm LGA1151 socket Processor, Max. 95W, PCH Q370
4 x U U-DIMM DDR4 non non-ECC SO SO-DIMM 2666MHZ up to 64GB
Support three display HDMI, DP, VGA
2x PCIex16, 3 x PCiex4, 2 x PCI, 1x M.2 NVMe , 1x mSATA
Standard Wall Mount Chassis
Great Scalability with 1x 3.5” +1x 2.5” or 2x 2.5” Front Front-asscessible drive bays
- 产品介绍
- 技术参数
- 订购信息
- 相关下载
The IPC-720B features as wall mount ruggedized PC chassis. It was designed to build-in industrial ATX motherboard. Itequipped with Intel@ 8/9th generation Corem /Pentium/Celeron processors to Support 95W Max and Intel@ Q370 chipsetIt comes with four DDR4 DIM socket up to 64GB DDR4 2666MHz with Non-ECC support and integrated HD Graphiccontroller.
IPC-720B operates temperature range from 0°C to 60°C. This is aimed at embedded applications for outdoor or semi-outdoor environment. Such as CNC, Compact machine controller, AOI with GPU card, Testing Equipment, Al with VPU &GPU 3D Image builder, outdoor systems installed in harsh environments, home automation and thin clients..etc.
| CPU | Intel ® 8/9th Generation(Coffee Lake Lake-S, Coffee Lake Lake-S Refresh) Core™ /Pentium/Celeron LGA 1151 socket Processor, Intel ® Q370 Express Chipset |
| Main Memory | 4 x DDR4 U U-DIMM memory Socket with non non-ECC support, up to 64GB 2666MHZ. |
| Display | 1 x VGA DB9 connector (resolution up to 1920x1080 @60Hz) 1 x HDMI1.4b connector (resolution up to 4096 x 2160 @ 30Hz) 1 x DP connector(resolution up to 4096 x 2304 @60Hz) Support VGA+HDMl+DP independent display |
| Storage | 7 x SATA IIl (6.0Gb/s) ports, support RAID 0/1/5/10 1 x mSATA 1 x M.2 22 x 80, support NVMe |
| Front I/O | Power status LED Power switch 2 x USB2.0 8 cm Chassis Fan 1x 3.5” +1x 2.5”or 2 x 2.5 “ drive bay |
| Rear I/O | 1 x VGA, 1x DP, 1x HDMI 4x USB2.0, 6 x USB3.0 4x RJ45 ( Intel I 211 Giga LAN chip) 2 x DB9 (RS232/RS422/RS485) 1 x AUDIO phone jack(Mic in, Line out, Line in) 4 x USB3.0 (by 1x 4 port USB3.0 expansion card) |
| Expansion Slot | 2 x PCIex16, 3 x PCIex4, 2 x PCI (M.2 and PCIe 4X slot1 only share one same PCIe3.0 signal) |
| Power | 1x AC input, 90~264AC input, ATX output ATX 400W power supply |
| Dimensions | 450(W) x 172 (H) x 482 (D) mm (w/o wall mount bracket) Weight: 11.4KG Chassis Color: Black |
| Mounting | Wall Mount |
| Environment | Board level operation temperture : 0°C to 60°C Storage temperture : -20˚C to 60˚C Relative humidty: 10% to 85% (operating, non-condensing) 5% to 95% (non-operating, non-condensing) |
| Certifications | Meet CE / FCC Class A |
| OS support | Windows 10 Linux |
| 型号 | IPC-720B |
| 可留言、电话或联系 sales@nexgemo.cn 获取 |
