Celeron® J1900, 4C4T, BTL DP, DVI-I, 2GbE, 2COM 1PCI, 1PCIex4

Onboard Intel® Celeron® processor J1900

1 x DP, 1 x DVI-I

2 x Intel® I210AT GbE LAN ports;LAN ports; support WoL, teaming and PXE

3 x USB 2.0, 1 x USB 3.0

2 x RS232/422/485

Front accessible 2.5 SSD/HDD and top accessible SD card for easy installation

2 x mini-PCIe socket for optional mSATA/Wi-Fi/3.5G/4G LTE/Fieldbus modules

Operating temp.: -5~55°C

Powered by the latest generation of Intel® Celeron® processor J1900 (formerly codenamed “Bay Trail-D”), NIFE 200P2/P2E presents intelligent PC-based controller and IoT gateway for factory automation. NIFE 200P2/P2E supports up to 8G DDR3L memory and have several options on storage devices like SD, mSATA, HDD and SSD. The NIFE 200P2/P2E support operating temperature from -5 up to 55 degree C with typical DC input 24V +/-20% range. The NIFE 200P2/P2Es has high integration ability with optional Mini-PCIe module and 2 x COM ports, which makes it a reliable connection with devices in factory automation applications (with optional PROFIBUS, ProfiNET, DeviceNET, EtherCAT, EtherNet/IP, CANopen, SERCOSIII master module), IoT applications (with optional GbE LAN, Wi-Fi, 3.5G/4G LTE module) and communication applications (with optional GPIO, RS232/422/485). NIFE 200P2/P2E is definitely the top choice for M2M intelligent system as a factory automation controller and gateway.

CPU & Memory

Intel® Celeron® Processor J1900 (2.0GHz, 4C4T, 10W)

Chipset - Bay Trail-D

Max. Memory - 2 x DDR3 SO-DIMM, 8GB Max.

GraphicDVI - 1

DP (Display Port) - 1

StorageHDD - 1 x 2.5" (SATA II)

mSATA - 1

SD Card - 1

External I/O1 x USB 3.0

3 x USB 2.0

LAN Ports - 2 x GbE

Audio - Mic-in, Line-out

Serial & GPIOSerial Port (External) * : isolation - 2 x RS232/422/485* (COM 1 support 2.5KV isolation protection)

Serial Port (internal) - 2, 10-pin header

GPIO - 4-in/4-out (internal)

ExpansionminiPCIe - 2, Full Size mini-PCIe Socket for mSATA/Wi-Fi/3.5G/4G LTE/Fieldbus modules

Expansion - 1 x PCI and 1 x PCIe x4

--Add-on card Length: 176mm max.

--Power consumption: 10W/slot max.

DimensionsPower Input Range - ATX, DC + 24V

Power Supply Adapter - Optional, 1 x 24V, 60W

System Dimension (WxDxH) - 151 x 157 x 214 mm

Carton Dimension (WxDxH) - 355 x 259 x 321 mm

Net weight - 3.3 kg

Gross weight - 4.3 Kg

Support OSWin7 32bit

Win7 64bit

Win10 64bit

NIFE 200P2E (P/N: 10J70020002X0)

Intel® Atom™ processor J1900 Quad Core 2.0GHz fanless system

24V, 60W AC/DC power adapter w/o power cord (P/N: 7400060047X00)
