NISE 2410 -J1900

Celeron® J1900, expansion fanless system, supoort one PCI slot

Onboard Intel® Celeron® Processor J1900 Quad Core, 2.00GHz

Dual independent display from DVI-I and HDMI

2 x Intel® I210IT GbE LAN ports; support WoL, teaming and PXE

4 x USB 2.0 & 1 x USB 3.0

2 x RS232 & 2 x RS232/RS422/RS485 with auto flow control

2 x mini-PCIe socket for optional mSATA/Wi-Fi/4G LTE/3.5G modules

Support -5 to 55 degree Celus extended operating temperature

Support 9-30V DC input

Powered by Intel® Celeron® Processor J1900 Quad Core, 2.0GHz. Driven by the latest Quad Core Intel® Celeron® Processor, NIE2410-J1900 can provide excellent computing power and is more power-efficient than the platforms based on the previous generation Intel® Celeron® product family.

NISE2410-J1900 supports up to 8G DDR3L memory and have several options on storage devices like CFast, HDD, SSD or mSATA . The NISE2410-J1900 comes with 1 x HDMI, 1 x DVI-I, 2 x GbE LAN ports, 2x COM port with RS232/422/485 and 5x USB ports including one USB 3.0. NISE2400-J1900 supports 9~30V DC input, and can be operated in an extended operating temperature range from -5 to 55 degrees Celsius. This Fanless system supports two mini-PCIe modules, which can be an excellent platform for IOT applications (with optional GbE LAN, Wi-Fi, 3.5G/4G LTE module) and factory automation applications with optional fieldbus module. Its expansion versatility makes NISE2410-J1900 a perfect platform for factory automation and M2M intelligent computing applications.

CPU & MemoryIntel Celeron J1900 (2.00GHz, 4C4T,10W)

Chipset:  Bay Trail

Max. Mem:  2 x DDR3L SO-DIMM, support 8GB Max.

GraphisDVI:  1, DVI-I

HDMI:  1

StorageHDD:  1

CFast Socket:  1

mSATA:  1

External I/O1 x USB3.0

4 x USB2.0

LAN Ports:  2 x GbE

Audio:  Mic-in, Line-out

Serial & GPIOSerial Port (External) * : isolation:  2 x RS232, 2 x RS232/422/485

GPIO:  4-in/4-out (Internal)


miniPCIe:  2

SIM Card Holder:  1

Expansion Slot:  1 x PCI

DimensionsPower Input Range:  ATX, DC +9 ~ 30V

Power Supply Adapter:  Optional, 1 x 24V, 60W

System Dimension (WxDxH):  195 x 200 x 90 mm

Carton Dimension (WxDxH):  335 x 294 x 193 mm

Net weight:  3 kg

Gross weight:  4.4 kg

Support OS

Win7 32bit

Win7 64bit

Win10 32bit

Win10 64bit

NISE 2410-J1900 (P/N:10J00241002X0)

Onboard Intel® Celeron® Processor J1900 Quad Core, 2.00GHz with one PCI expansion

24V 60W AC/DC power adapter w/o power cord (P/N: 7400060047X00)
